PARKSIDE 12 Volt cordless jigsaw »PSTKA 12 B3« without battery and charger
Characteristics
-
Constant Power Control – automatic power supply for constant cutting performance
- Fast sawing progress and optimal cornering thanks to 2-stage adjustable pendulum stroke
- Pendulum-free fine cutting adjustment
- Adjustable stroke rate
-
Cutting angles adjustable on both sides
- Surface-protecting plastic sliding shoe attachment
- Ergonomic handle area with anti-slip soft grip
-
Integrated LED work light
- Folding and removable saw guard made of transparent material
- Chip protection
-
Chip-free cutting line thanks to blower function
- Connection to external dust extraction – including extraction nozzle with reducer
- SAW LOCK keyless chuck for easy saw blade changes
- For standard saw blades with single-notch shank (e.g. from Parkside, Bosch, Metabo, Makita)
- 3-stage battery status indicator on the device
- Including carrying case
- Compatible with all PARKSIDE X 12 V Team series devices
- Delivery without battery and charger
Included accessories: 1x wood saw blade (Swiss Made), 1x metal saw blade (Swiss Made), 1x parallel stop, 1x adapter for external dust extraction including reducer, 1x Allen key.
Technical data
- Operating mode: 2 pendulum stroke levels + fine adjustment
- Idle stroke rate: 1500–2800 min-¹
- Stroke length: 18 mm
- Max. cutting depth: 70 mm in wood / 3 mm in aluminum
- Cutting angle: 0°/ left 22.5°, 45°/ right 15°, 30°, 45°
material
- Housing: polyamide, glass fiber (PA6 + GF30)
- Soft Grip: Thermoplastic Elastomer (TPE)
- Base plate: steel
Mass
- Jigsaw without battery: approx. 239 x 167 x 73 mm
- Case: approx. 325 x 238 x 118 mm
- Extraction nozzle: approx. 173 x Ø 39 mm
- Rip fence: approx. 220 x 71 x 29 mm
- Hexagon wrench: approx. 75 x 30 mm
- Dust extraction adapter: approx. 45 x Ø 35 mm
Weight
- Jigsaw without battery: approx. 1414 g
- BMC: approx. 752 g
- Suction nozzle: approx. 38 g
- Parallel stop: approx. 79 g
- Hexagon wrench: approx. 6 g
- Dust extraction adapter: approx. 12 g
